G11 board specifications and thickness selection: meet different application requirements

G11 board is a high-performance insulating material widely used in electronics, electrical, aerospace and other fields. Choosing the right G11 board specifications and thickness is essential to ensure product performance and quality.

Common specifications of G11 board

The specifications of G11 board usually include parameters such as size, thickness, color, etc. The following are common specification options:

1. Size

Standard size: The common standard size of G11 board is 1020mm × 1220mm or 1220mm × 2040mm, which is suitable for most industrial applications.

Customized size: According to specific needs, ZTelecgroup can provide G11 board with customized size.

2. Thickness

Common thickness: G11 board thickness usually ranges from 0.5mm to 50mm. Common thicknesses include 0.5mm, 1mm, 2mm, 3mm, 5mm, 10mm, 20mm, etc.

Special thickness: For special applications, G11 boards with non-standard thickness can be customized.

3. Color

Natural color: The natural color of G11 board is light yellow or light brown, which is the most common color.

Customized color: Other colors (such as black, green, etc.) can be selected according to demand, but it may affect the electrical properties of the material.

The selection of G11 board thickness

G11 board has a very wide range of thickness. The following factors need to be considered to select the appropriate thickness:

1. Mechanical strength requirements

For application scenarios that need to withstand large mechanical loads, such as structural support or force-bearing parts, thicker G11 boards need to be selected to increase their mechanical strength. Thicker boards generally have higher tensile strength and bending resistance.

2. Electrical performance requirements

In some high-voltage or high-current application scenarios, thicker G11 boards need to be selected to ensure sufficient electrical insulation performance. Thicker boards generally have higher breakdown voltages and better electrical stability.

3. Cost considerations

The thickness of the G11 board is closely related to the cost. Thicker boards are usually more expensive because they require more raw materials and processing costs. Under the premise of meeting performance requirements, choose the appropriate thickness to reduce costs.

4. Space constraints

In some space-constrained application scenarios, it is necessary to choose a thinner G11 board to save space. Thinner boards are easier to process and install, and can also reduce the overall weight of the product.

Selection considerations

1. Clearly define the application scenario: When selecting the specifications and thickness of the G11 board, you must first clarify the specific requirements of the application scenario, including electrical performance, mechanical strength, space limitations, and cost requirements.

2. Consult suppliers: Communicate with professional G11 board suppliers to understand their product specifications and performance characteristics, and make choices based on your needs.

3. Refer to industry standards: You can refer to relevant industry standards or technical specifications to understand the common specifications and thickness ranges of G11 boards, as well as recommended values in different application scenarios.

4. Sample testing: Before formally purchasing, you can ask the supplier to provide samples for testing to verify whether the selected specifications and thickness of G11 boards meet the application requirements.

Choosing the right G11 board specification and thickness is the key to ensuring that its performance meets application requirements. By comprehensively considering factors such as electrical performance, mechanical performance, installation space, processing performance and cost, you can find the most suitable G11 board to ensure that it performs best in your application.
