FR-4 anti-static fiberglass board



Brief description: FR-4 anti-static fiberglass board is a material specification that the resin material must be able to self-extinguish after being burned. A plate-like laminate product made of electronic cloth impregnated with epoxy phenolic resin and other materials and hot-pressed under high temperature and high pressure. It has high mechanical properties and dielectric properties, good insulation properties, heat resistance and moisture resistance, and It has good machinability and comes in four colors: white, light green, yellow and black.

Category: Insulating material board

Update time: 2023-12-11

Manufacturer nature: manufacturer



FR-4 anti-static fiberglass board



Composition of anti-static fiberglass board:

Composite material made of glass fiber and anti-static high mechanical strength resin

Features:

1. The appearance is beautiful and elegant, smooth and flat, with good flatness, smooth surface and no pits.

2. Good heat resistance and moisture resistance, good electrical properties in dry and wet states; low water absorption and not easy to deform.

3. High mechanical properties and good machinability.

It has excellent anti-static effect and is divided into three types: single-sided anti-static and double-sided anti-static/overall anti-static.

Single-sided anti-static fiberglass board:

One side is black and anti-static, and the other side is insulated and can withstand high temperatures.

Double-sided anti-static fiberglass board:

The inner substance is aqua-green glass fiber, and the surface is black with an anti-static surface.

Overall anti-static fiberglass board:

The anti-static value of any part is the same.

Anti-static performance value (resistance value):

Surface resistance value: 10^6-10^9 Ω

proportion

1.9-2.0

Operating temperature/performance

Temperature resistance up to 170℃, flame retardant (94-V 0).

Specification

1.0-60mm*1020*1220 mm More thicknesses can be customized.

The use of FR-4 anti-static fiberglass board
