product description
Features of Grade 155 Modified Polyester Enamelled Aluminium Round Wire
1. 155℃ heat resistance
2. High chemical stability
3. Good mechanical performance
Material of Grade 155 Modified Polyester Enamelled Aluminium Round Wire
155 ℃ modified polyester enameled wire paint with good performance
Standard of Grade 155 Modified Polyester Enamelled Aluminium Round Wire
Part of the criteria for adaptation or reference are：
GB/6109-2
Application of Grade 155 Modified Polyester Enamelled Aluminium Round Wire
Modified polyester aluminum round, flat wire, thermal class 155. The product has good thermal shock resistance, high softening breakdown temperature and excellent mechanical strength. Some typical applications include：
Motor
Instrument
Typical performance of Grade 155 Modified Polyester Enamelled Aluminium Round Wire
The following values do not apply to customized specifications
| Test | Standard requirements |
| Specification | Round wire：Ø0.3 mm—Ø3.0 mm |
| Resistivity | 0.02785Ω.mm2/m |
| Breakdown voltage | Round wire is above 5000V |
| Thermal shock | The minimum thermal shock temperature is 175℃ |
| Solvent resistant | Standard solvent, "H" hardness pencil insulation layer does not scratch |
| Appearance | Jujube red, smooth, shiny surface, no lacquer |
| Packaging | Standard plastic tray packaging |
Description：
The applicable scope of different enameled wire is different.
