product description
Features of Polyimide, Polyester Film, Modified Polyester Non-woven Cloth Wrapped Aluminum Wire
1. Can be wrapped in different combinations according to need
2. High dielectric strength
3. Smooth winding
Material of Polyimide, Polyester Film, Modified Polyester Non-woven Cloth Wrapped Aluminum Wire
National standard bare aluminium wire or extruded bare aluminum flat wire, smooth surface, small resistance
Polyimide, polyester film, modified polyester non-woven fabric as wrapping materials
Standard of Polyimide, Polyester Film, Modified Polyester Non-woven Cloth Wrapped Aluminum Wire
Part of the criteria for adaptation or reference are:
GB/T5584-99
Application of Polyimide, Polyester Film, Modified Polyester Non-woven Cloth Wrapped Aluminum Wire
Different wrapping methods are suitable for different environments. Some typical applications include:
Transformer
Electric reactor
Welder
Motor
Typical performance of Polyimide, Polyester Film, Modified Polyester Non-woven Cloth Wrapped Aluminum Wire
The following values do not apply to customized specifications
| Test | Standard requirements |
| Specification |
Round wire：Ø0.3 mm—Ø3.0 mm Flat wire：a side 0.8—5.0mm；b side 2.0—16mm |
| Resistivity | 0.02785Ω.mm2/m |
| Breakdown voltage | 1500V |
| Appearance | Wrap firmly, closely, evenly, without wrinkles |
| Packaging | Wood tray packaging, length can be customized |
Description：
You can choose different insulation materials for wrapping according to the need.
