product description
Features of Grade 200 Polyamide-imide Composite Polyester Aluminum Round, Flat Wire
1. High temperature resistant
2. Resistance to chemical corrosion, transformer oil
3. Resistance to coldness and radiation
4. High breakdown voltage
5. Good mechanical performance
Material of Grade 200 Polyamide-imide Composite Polyester Aluminum Round, Flat Wire
National standard bare aluminium wire or extruded bare aluminum flat wire, smooth surface, small resistance
Good insulating paint, polyester or polyester imide insulating paint as primer and polyamide imide as a top coat
Standard of Grade 200 Polyamide-imide Composite Polyester Aluminum Round, Flat Wire
Part of the criteria for adaptation or reference are:
IEC60317-0-3
IEC60317-25
IEC60317-0-2 (Flat)
IEC60317-29 (Flat)
MW36-A
MW36-A
Application of Grade 200 Polyamide-imide Composite Polyester Aluminum Round, Flat Wire
Grade 200 polyamide-imide composite polyester or enamelled aluminum round and flat wire have excellent performance in a variety of applications, including extreme applications. Some typical applications include:
Transformer (Including oil-immersed transformer)
Generator
Cooling system
C motor
UPS power supply
Typical performance of Grade 200 Polyamide-imide Composite Polyester Aluminum Round, Flat Wire
The following values do not apply to customized specifications
| Test | Standard requirements |
| Specification |
Round wire：Ø0.3 mm—Ø3.0 mm Flat wire：a side 0.8—5.0mm；b side 2.0—16mm |
| Resistivity | 0.02785Ω.mm2/m |
| Breakdown voltage | Round wire is above 5000V, flat wire is above 2000V |
| Thermal shock | The minimum thermal shock temperature is 220℃ |
| Softening breakdown | 320℃，2min without breakdown |
| Solvent resistant | Standard solvent, "H" hardness pencil insulation layer does not scratch |
| Appearance | Jujube red, smooth, shiny surface, no lacquer |
| Packaging | Plastic or wood tray packaging, flat wire length can be customized |
Description：
The applicable scope of different enameled wire is different, namely, the same enameled wire also have different paint film thickness.
