S(B)H15-M-30~1600/10 Series of Amorphous Metal Distribution Transformer

Amorphous transformer,Distribution transformer,Oil-immersed transformer
Amorphous transformer,Distribution transformer,Oil-immersed transformer
Amorphous transformer,Distribution transformer,Oil-immersed transformer
send email
chat online
leave message

Products Range

Our company can produce a variety of oil-immersed transformers with a voltage rating of 35kV or less and a capacity of 12500kVA or less. The variety includes S9, S11 series and S13, S15 series of energy-saving products. The product is widely used in industrial and mining enterprises, agriculture, civil construction and other distribution sites as well as oil, chemical industry, more oil, more chemical substances in the places.

Executive Standard:

GB1094     Electrical Transformer
IEC60076   Electrical Transformer
JB/T6451  Specification and Technical Requirements for Oil-immersed Power Transformers
JB/T10088   6kV~500kV Power Transformer Sound Level
GB/T7595     Quality of Transformer Oils in Service

Features of Products

Amorphous alloy is a new type of energy-saving material. Its metal atoms are disorderly amorphous, and its crystal structure is completely different from that of silicon steel, which is more conducive to magnetization and demagnetization. The iron core sheet is extremely thin, only 0.025mm, less than 1/10 of that of ordinary silicon steel. This new material is used for transformer cores and features high saturation magnetic induction, low loss, low excitation current, and good temperature stability. Amorphous alloy transformers have the advantages of low no-load loss, strong anti-short-circuit capability, advanced structure, energy saving, and obvious environmental protection advantages, and are currently ideal distribution transformers for energy saving.

Technical Parameters:
rated capacity
(KVA)
voltage group connection
 method
loss(KW) no-load
current(%)
Impedance
voltage(%)
outline dimension
(mm)
(L×B×H)
weight
(Kg)
gauge
High-voltage(KV) Low-voltage(KV) no-load load 75℃ vertical/
horizontal(mm)
30 11

10.5

10

6.3

0.4 Dyn11
or
Yyn0
33 600 1.5 4 920×850×830 410 550/550
50 43 870 1.2 1040×780×870 520 550/550
63 50 1040 1.1 1010×810×880 570 550/550
80 60 1250 1 1060×830×910 640 550/550
100 75 1500 0.9 1140×830×860 750 550/550
125 85 1800 0.8 1110×880×950 830 550/550
160 100 2200 0.6 1130×880×1000 940 550/550
200 120 2600 0.6 1240×900×1020 1090 660/660
250 140 3050 0.6 1290×900×1070 1250 660/660
315 170 3650 0.5 1380×840×1110 1470 660/660
400 200 4300 0.5 1420×920×1250 1710 660/820
500 240 5150 0.5 4.5 1360×1040×1180 1990 660/820
630 320 6200 0.3 1530×1120×1310 2390 820/820
800 380 7500 0.3 1880×1210×1360 2760 820/1070
1000 450 10300 0.3 2040×1520×1360 3240 820/1070
1250 530 12000 0.2 2140×1520×1430 3820 820/1070
1600 630 14500 0.2 2260×1540×1500 4620 820/1070

Note: 1.The load loss above the diagonal line in the table applies to the Dyn11 connection mode. The load loss below the diagonal line applies to the Yyn0 connection mode.
2. Due to continuous product improvement, the dimensions provided in this sample are for reference only. If necessary, our company can design and produce according to user requirements. Please contact the company in time.
