The description of S13-1600KVA three-phase oil-immersed transformer

S13-1600KVA three-phase oil-immersed transformer is a product developed on the basis of S9 series distribution transformers. It has the characteristics of low loss, low noise, strong short-circuit resistance, good shock resistance and good economic operation.

The features of S13-1600KVA three-phase oil-immersed transformer

Compared with the S9 transformer, this series of products has a no-load loss reduction of about 30% or more.

The iron core of S13-1600KVA three-phase oil-immersed transformer is made of high-quality, high-permeability silicon steel sheet and the full oblique multi-level seam is stacked.

The anchor body is positioned at multiple points, and all fasteners use anti-loosening nuts, which can withstand the test of vibration, bumps and inclined transportation and meet the requirements of non-lifting.

The high-voltage windings all adopt multi-layer cylindrical structure which improves the impact distribution of the windings.

The fuel tank can adopt a chip radiator or a corrugated fuel tank with an oil storage tank and a moisture absorber with an oil seal can be installed.

1.Energy saving of S13-1600KVA three-phase oil-immersed transformer

Compared with the original S7, the S9 type has an average reduction in no-load loss of 10.25%, a reduction in no-load current of 37.9%, and an average reduction in operating costs of 18.9%.

2. long service life of S13-1600KVA three-phase oil-immersed transformer

The S13-1600KVA three-phase oil-immersed transformer oil tank adopts a fully sealed structure. The fuel tank and the tank edge can be bolted or welded to death. The transformer oil does not contact the air to extend the service life.

3.High operational reliability of S13-1600KVA three-phase oil-immersed transformer

Improved the related parts of the fuel tank seal to increase the reliability and improve the process level to ensure the reliability of the seal.

4. small footprint of S13-1600KVA three-phase oil-immersed transformer

S13-1600KVA three-phase oil-immersed transformer tank adopts ripple radiator. When the oil temperature changes, the expansion and contraction of the corrugated plate can replace the role of the oil storage tank. The corrugated plate tank has a beautiful appearance and a small footprint.

The using condition of S13-1600KVA three-phase oil-immersed transformer

Altitude does not exceed 1000m.

Ambient temperature of S13-1600KVA three-phase oil-immersed transformer: higher temperature + 40 ℃; higher daily average temperature + 30 ℃; higher annual average temperature + 20 ℃; outdoor lower temperature -25 ℃.
