The description of insulation paper covered wire

Insulation paper covered wire is a wire that is extruded or drawn by oxygen-free copper rod or electric round aluminum rod through a mold of a certain specification and is wrapped by a specific insulating material. The combined wire is composed of several winding wires or copper and aluminum wires arranged according to the specified requirements. The winding wire of Insulation paper covered wire is wrapped by a specific insulating material.

Insulation paper covered wire mainly used for winding of oil-immersed transformers, reactors and other electrical devices.

Insulation paper covered wire category

Paper-coated copper (aluminum) flat wire, paper-coated copper (aluminum) coil wire, semi-rigid conductor paper-coated copper flat wire, copper wire wrapped with special insulating material, copper conductor combined wire, semi-hard copper conductor combined wire, thermal bonding acetal-coated composite wire, special insulation material-coated copper composite wire.

Insulation paper covered wire range

Paper covered rectangular copper and aluminum conductors:

Thickness: a: 1.00mm-10.00mm

Width size: b: 3.00mm-25.00mm

Paper-covered round copper and aluminum conductors: 3.00mm conductor diameter d _6.00mm

Combined wire copper and aluminum conductors:

Thickness: a: 1.00mm-6.00mm

Width size: b: 5.00mm-22.00mm

Semi-rigid copper flat conductor:

Thickness: a: 1.00mm-5.00mm

Width size: b: 3.00mm-16.00mm

Self-adhesive acetal enameled flat wire:

Thickness: a: 1.00mm-2.50mm

Width size: b: 5.00mm-15.00mm

If the specification of insulation paper covered wire exceeds the above range or other special conductors are used, please contact us.

The material of insulation paper covered wire

The soft copper flat wire for paper covered wires or combined wires conforms to the regulations of GB Ting 5584.2-85, and the resistivity at 20 ℃ is not greater than 0.01724 0 .mm2 / m. According to different mechanical strength requirements, the specified non-proportional extension strength RpO.2 for semi-hard copper conductors is recommended as follows:

C1 RpO.2 (> 100-180) N / mm2

C2 RpO.2 (> 181-220) N / mm2

C3 RpO.2 (> 221-260) N / mm2

The aluminum flat wire for paper covered wires or combined wires conforms to the provisions of GB5584.3, and the resistivity at 20 ℃ is not greater than 0.0280Ω.mm2 / m.

Wrapped insulation of insulation paper covered wire

Power cable paper, high-density insulation paper, high-elongation fiber paper, aromatic polyphthalamide paper and polyester fiber non-woven fabric.
